PAI Manufacturing
PAI Manufacturing is a subsidiary of Prescott Aerospace, Inc. This division supports our Customers Parker Hannifin, Atlas Aerospace, Spirit AeroSystems, Modern Industries and Genuine Machine. In July of 2021 we moved our two Phoenix locations into our new facility which consists of a 27,000 square foot climate-controlled building designed to support lean manufacturing and provide our employees with a clean, comfortable and safe working environment.
PAI Manufacturing
Equipment List
ENGINEERING/PROGRAMMING SYSTEMS
-
(1) MASTERCAM 3D SOLID MODELING SYSTEM CAD/CAM
-
(1) ABILE PROGRAMMING SOFTWARE FOR TSUGAMI SWISS CNC
-
(1) SOLIDWORKS 3D CAD MODELING SOFTWARE
Swiss
-
(1) TSUGAMI B0325 B-II CNC SWISS TYPE LATHE: 32 MM MAX BAR, 5-AXIS, 330 MM STROKE, 8000 RPM DUAL SPINDLES, FMB TURBO 3-38 12’ BARFEEDER, HI-PRESSURE COOLANT, FIRE TRACE FIRE SUPPRESSION SYSTEM
-
(1) CITIZEN L32 CNC SWISS TYPE LATHE: 32MM MAX BAR, 5-AXIS, 320MM STROKE, 8000 RPM DUAL SPINDLES, 12’ BARFEEDER
-
(4) CITIZEN L20 CNC SWISS TYPE LATHE: 20 MM MAX BAR, 5-AXIS, 200MM STROKE, 8000 RPM DUAL SPINDLES, 12’ BARFEEDER
INSPECTION EQUIPMENT
(TEMPERATURE CONTROLLED LAB)
- (1) MITUTOYO CRYSTA APEX V 574 CNC CMM, MCOSMOS PROGRAMMING SOFTWARE
- (1) BROWN & SHARPE GAGE2000 MANUAL CMM, PC-DMIS PROGRAMMING SOFTWARE
- (2) OGP OPTICAL COMPARATOR
- (1) MICRO VU OPTICAL COMPARATOR
- (1) TESA HITE 400 HEIGHT GAGE
- (1) MITUTOYO SJ-210 PROFILOMETER
- (1) 4’ x 8’ CALIBRATED SURFACE PLATE
- (1) PRATT & WHITNEY SUPERMICROMETER MODEL B – 20 MILLIONTHS ACCURACY, 10 MILLIONTHS REPEATABILITY
- (2) SUNNEN PG-800 BORE GAGE
- (**) ASSORTED CALIPERS, MICROMETERS, RING GAGES, PLUG GAGES, PIN GAGES, AND HEIGHT GAGES
Lathes
-
(1) HAAS ST30SSY CNC TURNING CENTER: MAX CUTTING 16″ DIA X 26″ LENGTH, 3.0” BAR CAPACITY WITH BAR LOADER
-
(1) PUMA 400 CNC TURNING CENTER: MAX CUTTING 21.7″ DIA X 41.0″ LENGTH, 4.5” BAR CAPACITY
-
(1) PUMA 300C CNC TURNING CENTER: MAX CUTTING 15.7″ DIA X 24.8″ LENGTH, 4.0” BAR CAPACITY WITH BAR LOADER
-
(1) PUMA 250B CNC TURNING CENTER: MAX CUTTING 15.7 DIA X 25.6″ LENGTH, 3.0” BAR CAPACITY WITH BAR LOADER
-
(1) PUMA 250B CNC TURNING CENTER: MAX CUTTING: 15.7″ DIA X 25.6″ LENGTH, 3.0” BAR CAPACITY
-
(1) OKUMA L470 CNC TURNING CENTER: MAX CUTTING 16.5″DIA X 25.5″ LENGTH, 3.8” BAR CAPACITY
-
(1) LEADWELL LTC-10AP CNC TURNING CENTER, FANUC CONTROL, 6.0” CHUCK
-
(3) HWACHEON HI-ECO 10E CNC TURNING CENTER, FANUC CONTROL, 6.0” CHUCK
-
(1) FAGOR ACCUTURN GT-27 CNC TURNING CENTER, GANG TOOLING PLATE, 4.0” CHUCK
-
(1) TRAK TRL 1840 SX CNC TURNING CENTER, SLX CONTROL, 10” FIXTURE PLATE
-
(2) TRAK TRL 1745 P CNC TURNING CENTER, LX2 CONTROL, 6” CHUCK
-
(4) CADILLAC MANUAL LATHES: CL4070G WITH DRO
-
(1) CADILLAC MANUAL LATHE: CL40100G WITH DRO
-
(1) CADILLAC MANUAL LATHE: MA-2560 WITH DRO
-
(1) CADILLAC MANUAL LATHE: 1940 WITH DRO
-
(1) ACRA MANUAL LATHE: 1440C WITH DRO
-
(1) SUMMIT MANUAL LATHE: 16-3X60
-
(1) ENCO FEELER MANUAL 5C CHUCKER-LATHE
Mills
-
(1) MATSUURA MX-520 5-AXIS CNC MACHINING CENTER: G-TECH 31I CONTROLLER, 20,000 RPM, 25HP HIGH SPEED SPINDLE, THROUGH-SPINDLE COOLANT, 60 TOOL CHAIN MAGAZINE, BT-40 SPINDLE TAPER.
-
(2) OKUMA 400HA HORIZONTAL CNC MACHINING CENTER: MAX VOLUME: 22.05″ X 24.01″ X 24.61″ ROTARY TABLE, 2 PALLETS 15.75″ X 15.75″
-
(1) SMT MCV 400 VERTICAL CNC MACHINING CENTER: TABLE: 18.11″ X 36.22″
-
(1) HAAS VF3DYT VERTICAL CNC MACHINING CENTER: TABLE: 18″ X 48″
-
(1) HAAS VF1D VERTICAL CNC MACHINING CENTER: TABLE: 14″ X 26″
-
(1) HAAS VF1 VERTICAL CNC MACHINING CENTER: TABLE: 14″ X 26″
-
(1) HAAS VF1 VERTICAL CNC MACHINING CENTER: TABLE: 16” X 18”
-
(2) ACRA MANUAL KNEE MILL
EDM
- (1) FANUC ROBOCUT ∝-C400iA 5-AXIS CNC WIRE EDM: 30.5” x 23.6” x 10.0” (L x D x H) MAX PART
Other
-
(1) BLUE M ELECTRIC OVEN: PARTLOW SERIES, 1000 CONTROL, PARTLOW MRC 5000 CHART RECORDER
-
(1) LEWIS CORP FNC 1000 ULTRA-SONIC CLEANING SYSTEM
-
(1) SANFORD MANUAL SURFACE GRINDER
-
(1) INGERSOLL-RAND SSR-HP30SE ROTARY AIR COMPRESSOR
-
(1) SULLAIR LS10 ROTARY AIR COMPRESSOR
-
(1) SULLAIR RN150 REFRIGERATOR AIR DRYER
